- SXS-762L: LR308 pattern receiver with DPMS thread pattern barrel nut (1 7/16" - 16). Fits LR308 pattern height receivers.
- SXS-762H: Armalite AR10 and DPMS "High" receivers with DPMS thread pattern barrel nut (1 7/16" - 16). Fits AR-10 height receivers.
Specifications (see additional specifications under the Specifications tab above):
- Material: 6061-T6 aluminum
- Finish: MIL-A-8625 type III class 2 anodizing
- Patent Pending
Profile | Length (in) | Attachment | Gas System Length | Weight (oz) | ID (in) | OD (in) |
Low | 15.00 | M-LOK | Any | 15.30 | 1.40 | 1.80 |
High | 15.00 | M-LOK | Any | 15.30 | 1.40 | 1.80 |
Low | 12.625 | M-LOK | Any | 13.60 | 1.40 | 1.80 |
High | 12.625 | M-LOK | Any | 13.60 | 1.40 | 1.80 |
How do I know what SXS-762 Profile (height) to choose?
There are two standard heights of .308 AR receivers on the market, Armalite/DPMS High, and DPMS low. The DPMS Low is not the same as the DPMS GII. To be sure you are choosing the correct Samson handguard for your AR10 style rifle, you can call the manufacturer of the receiver or measure from the center of the bore to the top of the receiver.
If it is approximately 1.32”, this is Armalite/DPMS high and you will need the SX-7.62H series. If it is roughly 1.25” it is DPMS low and you will need the SXS-7.62L series.
Measuring the height from the center of the bore to the top
of the receiver: To Measure the distance from the center of the bore to
the top of the receiver you will need a set of calipers. Measure the
diameter of the threads and divide that number by 2. Then measure from
the bottom of the threads to the top of the rail on the receiver. Use that result and subtract the divided number; which is the height from the center of the bore to the top of the receiver.
